Brandt KD-79-CF Corner Rounder Edgebander(USED, 2001)

Brandt KD-79-CF Corner Rounder Edgebander (USED, 2001)

Model: KD-79-CF
SN: 0-250-XXXX
Year: 2001
220/440V; 60Hz; 3~
Stock#: 1112-11

Product Details

* 0.4 mm to 8 mm (0.016" - 0.3125") Edgestrip thickness capacity

* 12mm – 50mm (1/2” - 2”) Panel thickness

* Automatic coil and strip feed magazine

* End trimming unit – (2) motors, 0.33 HP each, 12,000 RPM pneumatic indexing via program control, straight or chamfer up to 15°, mounted on precision THK ways

* Top & bottom fine trimming unit #1 – (2) trimming motors, 0. 5 HP, 12,000 RPM, tiltable from 0° to 15° with digital "quickset" system, pneumatic indexing via program control

* Top & bottom fine trimming unit #2 – (2) trimming motors, 0. 5 HP, 12,000 RPM, tiltable from 0° to 15° with digital "quickset" system, pneumatic indexing via program control

* Top & bottom contour trimming unit for corner rounding thick PVC, (2) trimming motors, 0.5 HP, 12,000 RPM

* Top & bottom scraping unit for finishing of roughly trimmed thick PVC edgings to remove the trimming marks, standard 3mm radius

* Buffing unit (top & bottom) - (2) motors, 2800 RPM

* Strengthened precutter for cutting PVC(max. 3 mm thick x 45 mm tall) from the coil

* PC-16 Program Control system for increased reliability and diagnostic assistance, no limit switches for setting operating units.

* Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator

* Control panel located at machine infeed for operator convenience

* Electronic frequency changer for all trimming motors which also incorporates electronic motor brakes

* Hot melt granulate glue application system with quick heat up time

* 36 Feet per minute feed speed

* Includes set of used tooling
